Medical Oxygen Concentrator

Development of urbanization with more energy consumption has brought about some negative impacts on human health. Pollution caused by automobile exhaust and industrial gases lead to higher incidence for respiratory diseases which usually occur on the trachea, bronchi, lungs or the chest. Patients suffering from respiratory diseases may feel difficult to breathe and are incapable to ingest enough oxygen. Some may even die from organ failure.

A high quality medical oxygen concentrator will be greatly helpful for the adjuvant therapy for patients with respiratory diseases. Our company can produce various types of medical oxygen concentrating machines suitable for different patients.

1. Our medical oxygen concentrator can output oxygen with concentration higher than 90% and it makes noise lower than 50dB while working.
2. Designed with reasonable structure, the machine components are wear-resistant and durable.
3. Our oxygen gas generator will help relieve your disease symptoms and balance the vital energy and blood in your body.
4. We have medical oxygen concentrators in various models such as the JAY-5/5Q, JAY-8 and the JAY-10. All our products are up to the standard of ISO9001. You can select a proper one according to your practical need.

Technical Parameters of Oxygen Concentrators for Medical Use

Model JAY-10 JAY-8 JAY-5 JAY-5Q
Flow rate 0-10L/min 0-8L/min 0-5L/min 0-5L/min
Oxygen concentration 1-9L/min, 93% (±3%)10L/min: 90% (±2%) 93% (±3%)
Outlet pressure 0.04-0.07Mpa
Noise level ≤50dB ≤50dB ≤50dB 40 db
Power AC220V(±10%), 50/60Hz (±1Hz); AC110V (±10%), 50/60Hz (±1Hz)
Power consumption ≤ 550W ≤480W ≤ 350W
LCD display Starting times, operating pressure, present working time, accumulated working time, preset time from 10mins to 40hours
Alarm Power failure alarm, high/low pressure alarm
Net weight 28kg 27kg 25kg 16 kgs
Size 365×375×600mm 320×360×600mm

1. Nebulizer (Atomizer)
2. Low concentration alarm: when oxygen concentration is 82% or above, the blue light will be on; when the oxygen concentration is blow 82%, the red light will be on.
3. Maintenance alarm: alarm for maintenance after 3000 hours' operation.
4. High temperature alarm: alarm for high temperature when the internal system temperature is above 50 ℃.
5. Pulse oximeter: fingertip pulse oximeter is available for monitoring patient's oxygen saturation on site.
6. Small LCD display: showing accumulated time, present working time and preset time.
7. Dual flow configuration
